Proto® 1/4" Drive Socket 1/8" - 6 Point
SKU
STP 4704
$0.00
Proto® 1/4" Drive Socket 1/8" - 6 Point
Proto® 1/4" Drive Socket 1/8" - 6 Point
Proto 6 Point Sockets are ideal for use on stubborn or damaged fasteners and also on fasteners made from soft materials. The TorquePlus design is a high performance drive configuration. The TorquePlus configuration employs a radius-corner design and shifting contact area. The TorquePlus internal design minimizes fastener rounding, helps to extend fastener life.
| SIZE [IN] | 1/8 |
|---|---|
| NUT END OUTSIDE DIAMETER [IN] | 1/4 |
| DRIVE END OUTSIDE DIAMETER [IN] | 5/32 |
| NUT DEPTH [IN] | 15/32 |
| BOLT CLEARANCE DEPTH [IN] | 11/32 |
| OVERALL LENGTH [IN] | 7/8 |
| WEIGHT [LBS] | 0.02 |
| DRIVE SIZE [IN] | 1/4 |
| POINT SIZE | 6 |
| FINISH | Full Polish |
| LENGTH TYPE | Standard |
| UNIT OF MEASURE | Fractional |
| SPECIFICATION ASME | ASME B107.110-2012 |
| NSN | 5120-01-648-6103 |
|---|---|
| GSA Item | Yes |
| FedMall Item | No |
| UPC | N/A |
