3/4" Drive Impact Socket 1" - 12 Point
SKU
STP 07516T
$0.00
3/4" Drive Impact Socket 1" - 12 Point
Proto ¾” Drive Impact Socket 1” – 12 Point
- Proto® 12 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
- The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
- Stamped size for easy reference.
- Side locking hole.
SIZE [IN] | 1 |
---|---|
NUT END OUTSIDE DIAMETER [IN] | 1-5/8 |
DRIVE END OUTSIDE DIAMETER [IN] | 1-5/8 |
NUT DEPTH [IN] | 5/8 |
BOLT CLEARANCE DEPTH [IN] | 15/16 |
OVERALL LENGTH [IN] | 2 |
WEIGHT [LBS] | 0.76 |
CRUSH RETAINING RING | JRR07523 |
O-RING | J07500R |
RETAINING PIN | J07500P |
DRIVE SIZE [IN] | 3/4 |
POINT SIZE | 12 |
FINISH | Black Oxide |
LENGTH TYPE | Standard |
UNIT OF MEASURE | Fractional |
GSA Item | Yes |
---|---|
FedMall Item | No |
UPC | N/A |
